Severe Environment Testing (SET)
Severe Environment Testing (SET)
Severe Environment Testing (SET) is a Samtec initiative to test certain products beyond typical industry standards and specifications, many of which are common requirements for harsh environment applications/industries.
Driven by demands for high functioning commercial standard interconnects, SET has proven beneficial in providing performance confidence, not only for rugged Mil/Aero industries and applications, but also for Automotive, Industrial and Medical applications.
Testing Specifications
Samtec interconnects are subject to a wide variety of standard test procedures that push the industry limits to help ensure quality and durability in any application. Severe Environment Testing includes Samtec’s standard Design Qualification Testing (DQT) and Extended Life Product™ (E.L.P.™) testing, along with additional testing for interconnect systems that will be used in more extreme/harsh applications or environments.
Samtec's SET products are approved for NASA Class D missions that require high-reliability, quick-turn and cost-effective solutions for LEO satellites, SmallSats, CubeSats and other space exploration applications.
Samtec utilizes NASA outgassing data to determine if certain products meet NASA’s ASTM E595-77/84/90 test requirements. See Samtec’s Outgassing FAQ for more information.
Additional Tests Included with SET:
- VITA™ 47.1 Module Insertions
- VITA™ 47.3 Humidity
- VITA™ 47.1 Operating Shock Class OS2
- VITA™ 47.1 Vibration Class VS3
- Exceeds VITA™ 47.1 Temperature Cycling Class C4
- Exceeds VITA™ 47.1 Non-Operating Temperature Class C4
- VITA™ 47.1 Electrostatic Discharge Resistance
- Exceeds VITA™ 47.1 Altitude for DWV
SET Qualified Products
Samtec offers an extensive portfolio of cost-effective interconnect solutions engineered for rugged environments. All testing is completed in-house and can be customized upon request for specific application requirements. Contact set@samtec.com for additional details and available test results.
Tiger Eye™ 1.27 mm Pitch Micro
|
|---|
|
SEARAY™ 1.27 mm Pitch
|
|---|
|
Razor Beam™ 0.50 mm Pitch
|
|---|
|
.100" (2.54 mm) Pitch Square
|
|---|
|
.050" (1.27 mm) Pitch Header &
|
|---|
|
Edge Rate® 0.80 mm Pitch
|
|---|
|
Tiger Eye™
|
|---|
|
mPOWER® 2.00 mm Pitch
|
|---|
|
SEARAY™ 0.80 mm Pitch
|
|---|
|
URSA™ I/O 1.00 mm Pitch
|
|---|
|
Tiger Eye™ .050" Pitch Discrete
|
|---|
|
Micro Mate™ 1.00 mm Pitch
|
|---|
|
High-Speed Micro Coax &
|
|---|
|
FireFly™ Copper
|
|---|
|
